Specification
| FEATURES | F007N-UL |
| Display | 7″ 16:9 TFT LCD |
| LCD Viewing Angles(T/B/L/R) | 85’/85’/85’/85′ |
| Resolution | 1024×600 |
| Colors | 24-bit |
| Brightness | 350 cd/m² |
| Backlight | LED |
| LCD Lifetime | 50000 hours |
| Touch Panel | Glass+Glass projective multi-touch capacitive touchscreen |
| CPU | 1GHz, Dual core Cortex-A7 |
| Storage | 4GB eMMC + 256MB DDR3 |
| RTC | Built-in |
| SD Card | NA |
| Ethernet port | 1*RJ45, based on10/100Mbps |
| USB Port | 1*USB Type-C 2.0 port, 1*USB Type-A 2.0 port |
| Download Method | USB slave / Flash drive/Ethernet |
| Serial port | COM1: RS232/RS485/RS422 COM2/COM4: RS485 COM3: RS232 |
| Rated power | ≤6W |
| Input Voltage | DC24V, working range DC9V-28V |
| Power supply protection | With lightning surge protection |
| Power Interruption Tolerance | <5mS |
| Certification | CE, RoHS, UL |
| Operating Temperature | -10-60℃ |
| StorageTemperature | -20-70℃ |
| UV Resistance | Operating in high UV environment is prohibited |
| Environmental Humidity | 10-90%RH (Non condensing) |
| Vibration Endurance | 10-25Hz (X,Y,Z direction 2G/30 minutes) |
| Cooling Mode | Natural Cooling |
| Protection Level | Front:IP65, Rear:IP20 |
| Enclosure Material | Zinc alloy + Engineering plastic |
| Cutout Size | 178mm×125mm |
| Dimensions | 185.1mm×130.9mm×32.6mm |
| Weight | About 600g |
